Inductive Load Bank

Name: Inductive Load Bank
Brand: APTEX INFOSOLUTIONS
Price: 150000 INR
Availability: InStock

Price 150000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Inductive Load Bank Specification

Power Factor
0.8

Overheating Protection
Yes, with alarm and auto shutdown

Connector Type
Copper bus bar

Surface Finish
Powder Coated

Shape
Rectangular

Operating Temperature
-10C to +50C

IP Rating
IP23

Efficiency
>98%

Humidity %
0-95% non-condensing

Mounting Type
Floor Mounted (Caster wheels provided)

Insulation Material
High Quality Fiberglass

Feature
Portable, Robust Construction, High Accuracy

Product Type
Inductive Load Bank

Application
Industrial

Protection Level
High with thermal cut-off

Frequency (MHz)
50 Hertz (HZ)

Rated Voltage
415 V AC

Energy Consumption
Resistive + Inductive Load operation

Output Type
Inductive

Color
Blue

Dimension (L*W*H)
2200 x 1000 x 1800 mm

Weight
1500 kg

Warranty
1 Year

Size
Customizable

Input Voltage
415 V AC

Phase
Three Phase

No Of Poles
3

Material
Mild Steel

Connection Type
Terminal Block

Enclosure Material
Electro-Galvanized Steel

Control Panel
Integrated with Digital Meter and Status Indicators

Compliance
IS 5553 / IEC 61010

Maintenance
Low Maintenance, Easy Access Panels

Acoustic Level
<75 dB(A) at 1 meter

Load Steps
Selectable in multiple steps

Voltage Class
Low Voltage

Service Life
Minimum 10 Years

Cable Entry
Bottom Entry

Mobility
Heavy Duty Wheels for Easy Movement

Cooling Type
Forced Air (Blower Assisted)

About Inductive Load Bank

Spotlight your industrial testing with our must-have Inductive Load Bank, a cost-effective, gilt-edged solution tailored for a wide array of applications. Featuring forced air (blower-assisted) cooling, this unit promises splendid performance with selectable multiple load steps and integrated digital meters for high accuracy. Its robust powder-coated, electro-galvanized steel enclosure, copper bus bars, and heavy-duty wheels ensure portability, durability, and easy movement. High efficiency (>98%), superior insulation, IP23 protection, and low maintenance requirements combine to deliver a perfect, dependable solution-making it the smart choice for commercial and industrial settings.

Splendid Commercial Versatility-Where Inductive Load Banks Excel

Inductive Load Banks are perfect for rigorous commercial and industrial uses such as generator, UPS, and transformer testing. Their robust build and high accuracy make them ideal for manufacturing plants, data centers, and power stations. Convenient mobility and low maintenance provide a competitive advantage, while rapid installation and customizable sizing meet dynamic application needs. Gilt-edged features, including comprehensive protection systems and overheating alarms, ensure safe performance, setting these banks apart from conventional alternatives in real-world operations.

Delivered Assurance: Sample Policy, Certifications, and Packaging

Our Inductive Load Banks are delivered nationwide at the lowest price, thanks to efficient logistics. Every unit is thoroughly packaged in secure, robust crates to prevent transit damage. Certified to IS 5553 and IEC 61010 standards, they meet global performance benchmarks. Upon request, samples can be supplied, ensuring complete satisfaction before bulk purchase. Stringent quality control and fully documented logistics support make the procurement process seamless for every customer, be it a manufacturer or supplier based in India.

FAQ's of Inductive Load Bank:

Q: How does the forced air (blower-assisted) cooling benefit the Inductive Load Bank?

A: The forced air (blower-assisted) cooling ensures efficient heat dissipation, supporting continuous operation without performance degradation. This allows for extended testing durations even under demanding load conditions.

Q: What types of industrial applications are ideal for this Inductive Load Bank?

A: This load bank is perfect for testing generators, UPS systems, transformers, and other power equipment in manufacturing industries, power plants, data centers, and commercial facilities needing precise load simulation.

Q: Where should the Inductive Load Bank be installed for optimal results?

A: Install the bank in ventilated industrial or commercial areas with flat flooring to take advantage of its floor-mounted design and easy mobility. Ensure proximity to electrical infrastructure for stable operation and safety.

Q: How easy is it to maintain the Inductive Load Bank?

A: Maintenance is low, with easy-access panels for straightforward inspection and servicing. The robust enclosure and high-quality materials further minimize upkeep, lowering downtime and operational costs.

Q: What certifications ensure the quality and safety of this product?

A: The load bank is certified to comply with IS 5553 and IEC 61010 standards, verifying its quality, safety, and adherence to recognized international guidelines.

Q: When should overheating protection be utilized during load testing?

A: Overheating protection automatically activates if abnormal temperature rises occur, triggering an alarm and auto shutdown to safeguard both the load bank and connected devices.
